The Visionopen ClampArm 5X LED is a clamp-mounted desktop magnifier that fixes to the edge of any desk, workbench, or table up to 55mm thick, freeing the entire desk surface of the base footprint that weighted-base desktop magnifiers occupy — a critical advantage for electronics workbenches, watchmaker’s benches, and craft tables where surface space is fully utilized by work materials and tools. The clamp mechanism uses a rubber-padded screw clamp rated to hold the magnifier arm securely against the desk edge without surface damage to wood, steel, or painted surfaces. The articulated arm extends 500mm from the clamp and includes two pivot joints with 360-degree rotation and friction locks, allowing the 90mm optical glass lens with 5x magnification to be positioned over any location on the work surface within a generous reach envelope. The LED ring consists of 18 daylight LEDs at 6500K with a sliding brightness control on the arm body. The arm folds flat against the clamp column for compact storage when the magnifier is not in use. USB-C powered with a 1.8m braided cable. Compatible with desks 10mm to 55mm thick. Weight excluding clamp: 440g.
Visionopen ClampArm 5X LED — Clamp-Mount Desk Magnifier
70 $ Original price was: 70 $.57 $Current price is: 57 $.
Visionopen ClampArm 5X LED — desk-clamp mount to 55mm, 500mm articulated arm, 90mm optical glass 5x, 18-LED 6500K, sliding brightness, USB-C braided cable, folds flat. Weight 440g.
Be the first to review “Visionopen ClampArm 5X LED — Clamp-Mount Desk Magnifier” Cancel reply
